Skinod Medical
Electronic Clinical Thermometer
SK-T998 More +
Data Interface: Parallel interface / USB
Image Enhance: multi-gear detail boosting
Image Calibration: Shutter calibration
Pantone: White hot / black hot / multiple pseudo-color plates
Temperature Correction: Manual / automatic
Temperature Data Output: Real time parallel output
Measuring Statistics: Max / min statistics,temperature analysis
| Resolution | 256×192 |
| Pixel Spacing | 12μm |
| Viewing Angle | 25.5°×19.2° |
| Image Frame Rate | 25Hz/15Hz |
| NETD | ≤60mK@f#1.0 |
| Working Temperature | -15℃～+60℃ |
| Supply Voltage | 3.8V-5.5V DC |
| Power Consumption | <200mW* |
| Weight | <18g |
| Size/mm | 20*20*21 |
| Data Interface | Parallel interface / USB |
| Control Interface | SPI/I2C/USB |
| Image Enhance | multi-gear detail boosting |
| Image Calibration | Shutter calibration |
| Pantone | White hot / black hot / multiple pseudo-color plates |
| Measuring Range | 0℃~+60℃ |
| Measuring Accuracy | ±0.5℃ |
| Temperature Correction | Manual / automatic |
| Temperature Data Output | Real time parallel output |
| Measuring Statistics | Max / min statistics,temperature analysis |
